Jiangxi Nanma Electrical Co., Ltd. introduces the XCMD2115L1, an adjustable roller lever limit switch built for lateral cam‑driven position monitoring. Designed to adapt to diverse on‑site assembly conditions, this industrial limit switch helps tackle common alignment challenges encountered during equipment assembly and commissioning. It brings multiple practical features optimized for real‑world workshop applications.
Design & Operational Highlights
Rotary head with plastic roller, 30° cam actuation angle
Compact 30×50×16 mm snap‑action design, suitable for installation inside machine guards and narrow confined spaces.
Two housing options available: metal housing for superior mechanical robustness, flame‑retardant PBT plastic for general‑purpose indoor automation.
1 NC +1 NO contact configuration, fully compatible with conventional relay and PLC input circuits.
IP66/IP67/IP68 ingress protection together with IK06 impact resistance; resistant to cutting fluid, dust and wash‑down workshop conditions.
Certified with CE, CB, CQC and RoHS to support global project procurement.
Typical Applications
Tailored for sideways mechanical actuation, the adjustable roller lever limit switch delivers consistent stroke and position signals for machine tools, automated production lines, packaging machinery, conveying systems, woodworking and textile equipment. This industrial limit switch performs reliably for slide end‑stop detection, safety gate monitoring and turntable indexing tasks, especially suited for applications with minor unavoidable cam‑mounting misalignment.
About Us
Jiangxi Nanma Electrical Co., Ltd. develops and manufactures industrial control components including the industrial limit switch. Backed by in‑house R&D and automated production lines, the company offers OEM & ODM services together with professional technical support for worldwide automation buyers.
FAQ
Q: Is the XCMD2115L1 pre‑fitted with a cable?
A: Yes, XCMD2115L1 comes with a factory‑fitted 1‑meter cable exiting from the end of the switch body. Custom cable lengths are available upon request.
Q: What actuation angle does this switch require?
A: Position signal switching is triggered at 30° cam actuation angle.
Q: What housing material options are available for XCMD2115L1?
A: Two options are offered: metal housing for higher mechanical shock resistance and flame‑retardant PBT plastic housing for general‑purpose indoor automation scenarios.
