CSK-44 Quadruple Magnetic Blowout Limit Switch

Product Introduction:

The CSK-44 magnetic blowout four-gang switch is equipped with four independent roller linkage stainless steel lever transmission components and an integrated linkage rocker structure. The external limit block presses against the rollers to synchronously drive the four internal contacts to open and close simultaneously. The multi-layer metal transmission bracket structure is stable, impact-resistant, and wear-resistant, and can be adapted to long-term high-frequency reciprocating impact triggering in industrial equipment. The entire shell is made of thickened blue flame-retardant engineering plastic through one-piece injection molding, which is high-temperature resistant, flame-retardant, insulating, and drop-resistant, effectively preventing dust and oil from entering the switch cavity, making it suitable for harsh workshop conditions with heavy dust and oil. The switch has four independent silver alloy moving and stationary contacts and a separate magnetic blowout arc extinguishing device. The arc is quickly broken by the magnetic field generated by the built-in permanent magnet at the moment of contact breakage, effectively avoiding arc adhesion and contact erosion, and significantly extending the service life of the switch under heavy load conditions. The base has reserved standard mounting holes of multiple specifications, which can be firmly locked with screws. The four independent and separate wiring terminals are clearly and neatly arranged, and the wiring is firmly secured and not easy to loosen. The product utilizes mature magnetic blowout arc extinguishing technology combined with a four-way, four-circuit design. A single mechanical trigger can simultaneously control four electrical circuits, meeting the multi-channel synchronous interlocking protection requirements of equipment. The high-purity silver contacts are oxidation-resistant and can withstand millions of repeated switching cycles. The flame-retardant insulating shell isolates the risk of leakage. It operates stably in production environments with high dust and light oil contamination. The four-roller lever is compatible with various cams and limit stop triggering structures. It is widely used in cranes, large die-casting equipment, fully automated production lines, and heavy engineering machinery for extreme travel protection, four-way electrical interlocking, and multi-point signal feedback acquisition.

Key selling points：

1. 4-circuit synchronous linkage design, one trigger controls four independent circuits

2. Magnetic blow-out arc extinguishing system, effectively avoid arc burn on contacts

3. Pure silver alloy contact, over 1,000,000 times mechanical service life

4. Flame retardant plastic housing, dustproof & oil resistant for harsh industrial environment

5. Standard mounting holes, flexible installation for crane, machine tool and automation equipment

Detailed application scenarios：
The CSK-44 quadruple magnetic blow-out switch is specifically developed for multi-circuit synchronous control applications. It is widely used in bridge cranes, gantry cranes, and tower cranes for limit protection, enabling synchronous power cut-off of multiple lifting/traveling circuits. It is also compatible with die-casting machines and heavy-duty injection molding machine tools for limit interlocking, allowing for simultaneous disconnection of four circuits to ensure equipment safety. Furthermore, it is applied to fully automated production lines, heavy-duty conveying machinery, small mining equipment, and electrical control points in engineering machinery, enabling synchronous feedback of multiple signals and electrical safety interlocking protection. It is the preferred limit switch accessory for multi-circuit industrial control equipment.
